Bromic Heating Affinity Smart-Heat Control Eclipse

Bromic Heating's new Eclipse Pendant Controls give customers complete control over both heating and light output. These units require a smart device with internet connectivity, as well as the Bromic Smart-Heat App which is available on the App Store and Google Play Store.

The 1 channel provides both Bluetooth and Wi-fi communication capabilities for Bromic App control. The 5 channel controllers include options for ethernet connectivity or BMS integration via 0-10 VDC built-in, whereas these features can be added to the 1 channel controllers via an optional expansion board.

The Smart-Heat Control operates using a smart device with a Bluetooth or Wi-Fi connection. The mounting location of the Smart-Heat Control must be selected to ensure that it is within range for the selected communication method. Refer to Installation Manual for mounting location requirements.

The Bromic Smart-Heat App is available on the App Store and Google Play Store.

Documents:

• Wireless Controls Catalogue
• Affinity Eclipse Controls Briefing / Spec Sheet
• Instruction Manual
